| Outer Dimensions | L2150*W1145*H450-700mm (±10mm) |
| Mattress platform | L1940*W830 mm (±10mm) |
• 4-section sleeping surface molded by cold-rolled steel sheet
• Removable ABS/Polypropylene plastic head and foot ends with color panels
• Lockable and fold-away Polypropylene full-length side rails
• IV pole sockets located at four corners
• Four lockable castors Ø5" with central brake system
• High-quality medical motor system with 4 motors, 1 control box and 1 handset
• 4 pcs urine bag hooks
• Height adjustable IV pole, foam mattress, over-bed table, oddment shelf, CPR, etc.
| Backrest | 0 ~ 70°(±5°) |
| Legrest | 0 ~ 35°(±5°) |
| Trendelenburg/Reverse T. | 0 ~ 12°(±2°) |
| Height | 450-700mm (±10mm) |
| Weight capacity | 170kg |
| Power supply | 220V/110V, 50HZ/ 60Hz |
| Maximum input | 1.6A, 450VA |
ISO 9001, ISO 13485, CE, FDA
| G.W. | 115.7kg |
| N.W. | 108.5kg |
• One set to two export Cartons
• 2 year on electronics and motors
• 5 years on frame and structural components
