| Outer Dimensions | L2165*W1080*H400-800mm (±10mm) |
| Mattress platform | L1930*830Wmm(±10mm) |
• 4-section sleeping surface of powder-coated steel slat, with steel brackets for positioning matress
• Removable MDF wooden head and foot ends
• Lockable and fold-away MDF wooden side rails
• IV pole sockets located at four corners
• Four lockable castors Ø5“ with central brake system
• High-quality medical motor system with 4 motors, 1 control box and 1 handset
• 4 pcs urine bag hooks
• Height adjustable IV pole, foam mattress, over-bed table, oddment shelf, manual/ electronic CPR, etc.
| Backrest | 0 ~ 70°(±5°) |
| Legrest | 0 ~ 35°(±5°) |
| Trendelenburg/Reverse T. | 0 ~ 12°(±2°) |
| Height | 200-765mm(±10mm) |
| Weight capacity | 250kg |
| Power supply | 220V/110V, 50HZ/ 60Hz |
| Maximum input | 1.6A, 450VA |
• One set to one export Ctn
• Ctn Size: 206x95x36cm
• 2 year on electronics and motors
• 5 years on frame and structural components
