| Outer Dimensions | L2102*W950*H490-780mm(±10mm) |
| Mattress platform | 1950L*830Wmm(±10mm) |
• 4-section sleeping surface molded by PP plastic sheet
• Removable ABS plastic head and foot ends with color panels
• Lockable and fold-away powder-coated steel side rails
• IV pole sockets located at four corners
• Four lockable castors Ø5"
• High-quality medical motor system with 4 motors, 1 control box and 1 handset
• 4 pcs urine bag hooks
• Height adjustable IV pole, foam mattress, over-bed table, oddment shelf, manual/ electronic CPR, etc.
| Backrest | 0~70°（±5°） |
| Legrest | 0 ~ 35°(±5°) |
| Trendelenburg/Reverse T. | 0 ~ 12°(±2°) |
| Height | 490-780mm(±10mm) |
| Weight capacity | 200kg |
| Power supply | 220V/110V, 50HZ/ 60Hz |
| Maximum input | 1.6A, 450VA |
ISO 9001, ISO 13485, CE, FDA
| G.W. | 108kg |
| N.W. | 102kg |
• One set to one export Ctn
• Ctn Size: 206*98*34cm
• 2 year on electronics and motors
• 5 years on frame and structural components
